2603 Airbag

$279.00$415.00

SKU: N/ACategory:
Bellows

Triple

Like the BOSS double bellow, the 2603 triple bellow Airbag has proven over the years to have superior toughness

Used for example in the BOSS replacement kit for the Land Rover Discovery2

Perfect for lifted vehicles and has volume to give heavier vehicles a quality ride

Description

  • BAG CAPACITY:               2600lb (or 1181kgs) @ 100psi
  • FREE HEIGHT:                  250mm (sitting on the bench)
  • MAX HEIGHT:                   380mm
  • FULLY COMPRESSED:    85mm
  • MAX DIAMETER:             190mm (fully compressed)
  • WORKING PRESSURE:   0-160psi
