2403 Airbag
Price range: $220.00 through $335.00
| Bellows | Triple |
|---|
The BOSS triple bellow 2403 Airbag is ideal when width is limited, but height is required
Compatible with BOSS bracketry and suitable lifted vehicles
Great for custom builds
Similar to the 2400 Bag but with even more lift range
Note: the above ‘BAG 2500/2400 End Plate’ diagram relates to our Bag Completes only
Description
- BAG CAPACITY: 2400lb (or 1088kgs) @ 100psi
- FREE HEIGHT: 210mm (sitting on the bench)
- MAX HEIGHT: 285mm
- FULLY COMPRESSED: 85mm
- MAX DIAMETER: 135mm (fully compressed)
- WORKING PRESSURE: 0-160psi
