2400 Airbag

$195.00$299.00

Boss
SKU: N/ACategory:
Bellows

Double

The Boss Double Bellow 2400 Airbag is ideal when width is limited

Used in our Load Assist Kit for the earlier model Amarok to avoid other suspension components

It is also used in many projects and custom builds

Similar to the 2401 but with more lift range

Description

  • BAG CAPACITY:                2400lb (or 1088kgs) @ 100psi
  • FREE HEIGHT:                   140mm (sitting on the bench)
  • MAX HEIGHT:                    185mm
  • FULLY COMPRESSED:     65mm
  • MAX DIAMETER:              135mm (fully compressed)
  • WORKING PRESSURE:    0-160psi
